APC Symmetra LX
High-Availability Power Protection with Symmetra LX
High-Availability Power Protection with Symmetra LX
The Symmetra LX is a high-performance, double-conversion on-line uninterruptible power supply (UPS) engineered to provide highly available, redundant, and scalable power protection for your critical IT infrastructure. Recognizing that modern IT demands agility, the Symmetra LX is the first UPS to offer both redundancy and scalability within a single, space-saving chassis. Designed to safeguard hardware, software, and data, it ensures continuous power delivery from its internal batteries until utility lines are restored to a safe level.
Whether you are outfitting a server room, a data center, or a distributed network environment, the Symmetra LX series delivers a robust architecture that grows seamlessly with your business, ensuring you never pay for more capacity than you currently need.
Solving Modern Power Challenges
The Problem
Modern IT environments face a dual challenge: the critical need for uninterrupted uptime and the unpredictability of future power demands. Power disturbances such as blackouts, brownouts, surges, and sags can instantly cripple operations, damage expensive electronic equipment, and corrupt valuable data. Furthermore, traditional UPS systems force businesses to estimate their future power needs up front, often leading to costly over-provisioning or the need for a complete “rip-and-replace” upgrade when capacity is exceeded. Maintaining traditional UPS systems also typically requires bringing down mission-critical loads, resulting in planned downtime.
The Solution
The Symmetra LX eliminates these pain points through its modular, redundant architecture. By allowing you to scale both power capacity and runtime as your demand increases, it completely removes the guesswork from capacity planning. If higher levels of availability are required, the system can be configured for N+1 internal redundancy. To solve the issue of maintenance downtime, the Symmetra LX features hot-swappable modules, ensuring you never have to bring down your mission-critical loads to service the unit or add capacity.
Key Features
Why Choose Symmetra LX
The double-conversion on-line design ensures a pure sine wave output with zero transfer time, completely isolating your critical load from utility power anomalies.
Lower Total Cost of Ownership (TCO)“Pay as you grow” scalability allows you to invest only in the power and runtime modules you need today, seamlessly expanding your infrastructure as your business scales. High efficiency (up to 90% at full load) minimizes energy consumption and cooling costs.
Because all primary components are hot-swappable—and because the system features automatic and manual internal bypass capabilities—routine maintenance and capacity upgrades can be performed while the UPS continues to protect the load.
Seamless IT IntegrationRack-mount models ship with standard receptacles, while the system’s removable input/output wiring trays and robust communication interfaces guarantee smooth integration into any server room or data center.
Real-World Deployments
K-12 Education and Distributed IT Environments
As educational institutions heavily integrate technology—such as 1:1 computing initiatives and online standardized testing—reliable IT infrastructure is no longer a luxury, but a necessity. Devices like routers that provide critical internet connections draw relatively little power but must remain online during utility disruptions; the Symmetra LX can power this essential network gear for hours. When deployed in a secure enclosure (like a NetShelter rack), the Symmetra LX provides the essential power protection needed to keep 21st-century classrooms online. Furthermore, organizations can often leverage funding programs, such as the federal E-rate program, which offers substantial rebates for deploying essential power protection, racks, and enclosures.
Specifications and Product Comparison
The Symmetra LX series requested below comes in two main regional variants:
- P / RMP Models (208V/240V): Designed primarily for North American standards, supporting 208V or 240V nominal input/output.
- I / RMI Models (230V): Designed for international markets, supporting 220/230/240V (single phase) or 380/400/415V (3-phase) input, with 230V nominal output.
All listed models feature a 90% efficiency rating at full load and use the SYBT5 maintenance-free sealed lead-acid battery module.
4 kVA to 8 kVA Scalable Models
Ideal for smaller server rooms or network closets expecting moderate growth.
SYA4K8P
Tower, 208V. 4 kVA scalable to 8 kVA N+1. Weight: 347 lbs (157.8 kg). Dimensions (HxWxD): 26.42″ x 19.00″ x 28.60″.
SYA4K8I
Tower, 230V. 4 kVA scalable to 8 kVA N+1. Weight: 157.7 kg. Dimensions (HxWxD): 671mm x 483mm x 726mm.
SYA4K8RMP
Rack-Mount, 208V. 4 kVA scalable to 8 kVA N+1. Form Factor: 13U. Weight: 295 lbs (134.1 kg).
SYA4K8RMI
Rack-Mount, 230V. 4 kVA scalable to 8 kVA N+1. Form Factor: 13U. Weight: 134.1 kg.
8 kVA Models
For environments currently requiring up to 8 kVA of redundant power.
SYA8K8RMP
Rack-Mount, 208V. 8 kVA scalable to 8 kVA N+1. Form Factor: 13U. Weight: 392 lbs (178.2 kg).
SYA8K8RMI
Rack-Mount, 230V. 8 kVA scalable to 8 kVA N+1. Form Factor: 13U. Weight: 178.2 kg.
8 kVA to 16 kVA Scalable Models
Provides a highly scalable foundation for rapidly growing IT loads.
SYA8K16RMP
Rack-Mount, 208V. 8 kVA scalable to 16 kVA N+1. Form Factor: 19U. Weight: 437 lbs (198.6 kg).
SYA8K16RMI
Rack-Mount, 230V. 8 kVA scalable to 16 kVA N+1. Form Factor: 19U. Weight: 198.7 kg.
12 kVA to 16 kVA Scalable Models
Designed for larger, high-density server configurations demanding substantial base power.
SYA12K16RMP
Rack-Mount, 208V. 12 kVA scalable to 16 kVA N+1. Form Factor: 19U. Weight: 534 lbs (242.7 kg).
SYA12K16RMI
Rack-Mount, 230V. 12 kVA scalable to 16 kVA N+1. Form Factor: 19U. Weight: 242.7 kg.
16 kVA Models
Maximum capacity within a single standard chassis, offering peak power with built-in redundancy options.
SYA16K16RMP
Rack-Mount, 208V. 16 kVA scalable to 16 kVA N+1. Form Factor: 19U. Weight: 631 lbs (286.8 kg).
SYA16K16RMI
Rack-Mount, 230V. 16 kVA scalable to 16 kVA N+1. Form Factor: 19U. Weight: 286.9 kg.
Symmetra LX Specifications Comparison
Here is a comprehensive product specification table for the requested Symmetra LX models. Designed for IT professionals and facility managers, the Symmetra LX series features a modular, redundant architecture that allows you to scale power and runtime as your business demands increase.
By reviewing these specifications, you can easily identify the correct voltage, form factor, and scalable power capacity that fits your specific server room or data center requirements.
| Product SKU | Form Factor & Height | Nominal Voltage | Base Capacity & Scalability | Dimensions (H x W x D) | Weight |
|---|---|---|---|---|---|
| SYA4K8P | Tower | 208V / 240V | 4 kVA (Scalable to 8 kVA N+1) | 671 x 483 x 726 mm | 157.8 kg (347 lbs) |
| SYA4K8I | Tower | 230V | 4 kVA (Scalable to 8 kVA N+1) | 671 x 483 x 726 mm | 157.7 kg |
| SYA4K8RMP | Rack-Mount (13U) | 208V / 240V | 4 kVA (Scalable to 8 kVA N+1) | 572 x 472 x 688 mm | 134.1 kg (295 lbs) |
| SYA4K8RMI | Rack-Mount (13U) | 230V | 4 kVA (Scalable to 8 kVA N+1) | 572 x 472 x 688 mm | 134.1 kg |
| SYA8K8RMP | Rack-Mount (13U) | 208V / 240V | 8 kVA (Scalable to 8 kVA N+1) | 572 x 472 x 688 mm | 178.2 kg (392 lbs) |
| SYA8K8RMI | Rack-Mount (13U) | 230V | 8 kVA (Scalable to 8 kVA N+1) | 572 x 472 x 688 mm | 178.2 kg |
| SYA8K16RMP | Rack-Mount (19U) | 208V / 240V | 8 kVA (Scalable to 16 kVA N+1) | 836 x 472 x 688 mm | 198.6 kg (437 lbs) |
| SYA8K16RMI | Rack-Mount (19U) | 230V | 8 kVA (Scalable to 16 kVA N+1) | 836 x 472 x 688 mm | 198.7 kg |
| SYA12K16RMP | Rack-Mount (19U) | 208V / 240V | 12 kVA (Scalable to 16 kVA N+1) | 836 x 472 x 688 mm | 242.7 kg (534 lbs) |
| SYA12K16RMI | Rack-Mount (19U) | 230V | 12 kVA (Scalable to 16 kVA N+1) | 836 x 472 x 688 mm | 242.7 kg |
| SYA16K16RMP | Rack-Mount (19U) | 208V / 240V | 16 kVA (Scalable to 16 kVA N+1) | 836 x 472 x 688 mm | 286.8 kg (631 lbs) |
| SYA16K16RMI | Rack-Mount (19U) | 230V | 16 kVA (Scalable to 16 kVA N+1) | 836 x 472 x 688 mm | 286.9 kg |
(Data sourced from for 208/240V “P” and “RMP” models; for 230V “I” and “RMI” models).
How to Choose the Right Model for Your Needs
If you are a buyer evaluating these systems, understanding the naming conventions and features will help ensure this product perfectly aligns with your infrastructure:
Models ending in “P” or “RMP” are optimized for North American 208V/240V nominal inputs and outputs. Models ending in “I” or “RMI” are built for International deployment, supporting 220/230/240V (single phase) or 380/400/415V (3-phase) nominal inputs and 230V outputs.
Select Your Form Factor (Tower vs. Rack-Mount)Rack-mount variants (denoted by “RM”) are designed to seamlessly integrate into standard IT enclosures, taking up 13U for up to 8 kVA chassis and 19U for 16 kVA chassis. Tower options stand independently and are ideal for areas lacking dedicated rack space, like distributed network closets.
Symmetra LX’s modularity means you can configure the system for N+1 internal redundancy. For example, the SYA8K16RMP ships with 8 kVA of power out of the box, but resides in a 16 kVA-capable frame. This allows you to hot-swap additional power modules into the chassis as your load increases, completely eliminating the need for costly “rip-and-replace” upgrades.
Hot-Swappable MaintenanceAll modules—including batteries, power modules, and intelligence modules—can be replaced without powering down the connected IT load, which effectively translates to zero planned downtime.
Symmetra LX Product Categories
Rack-Mount (RM) UPS Models
High-density redundant power for server environments in 13U and 19U rack configurations.
Extended Run (XR) Tower Models
Extended runtime tower configurations with additional battery capacity for prolonged outages.
Battery Modules & XR Frames
Replacement battery modules and extended run battery frames for all Symmetra LX configurations.
Symmetra PX Battery Frames
Battery frames compatible with the Symmetra PX platform for scalable energy storage.
Service Bypass Panels & PDU
Maintenance bypass panels and power distribution for uninterrupted service during UPS maintenance.
Hardware Options, Cables & Parts
Accessories, cables, power modules, intelligence modules, and replacement parts for the Symmetra LX platform.
