APC NetShelter SX
Low to High Density Server and Networking Applications

RoHS

Overview:

World's most versatile rack enclosure for demanding IT environments

The APC NetShelter SX is the next generation rack enclosure solution influenced by 10 years of customer feedback and addresses current IT market trends for high-density server and networking applications. With a strong focus on cooling, power distribution, cable management and environmental monitoring, the NetShelter SX provides a reliable rack-mounting environment for mission-critical equipment.

APC NetShelter SX
NetShelter SX 24U 600mm Wide x 1070mm Deep Enclosure

APC NetShelter SX 24U 600mm Wide x 1070mm Deep Enclosure

NetShelter SX 42U 600mm Wide x 1070mm Deep Enclosure

APC NetShelter SX 42U 600mm Wide x 1070mm Deep Enclosure

NetShelter SX 42U 600mm Wide x 1200mm Deep Enclosure

APC NetShelter SX 42U 600mm Wide x 1200mm Deep Enclosure

NetShelter SX 42U 750mm Wide x 1070mm Deep Enclosure

APC NetShelter SX 42U 750mm Wide x 1070mm Deep Enclosure

NetShelter SX 42U 750mm Wide x 1200mm Deep Enclosure

APC NetShelter SX 42U 750mm Wide x 1200mm Deep Enclosure

NetShelter SX 48U 600mm Wide x 1070mm Deep Enclosure

APC NetShelter SX 48U 600mm Wide x 1070mm Deep Enclosure

NetShelter SX 48U 600mm Wide x 1200mm Deep Enclosure

APC NetShelter SX 48U 600mm Wide x 1200mm Deep Enclosure

NetShelter SX 48U 750mm Wide x 1070mm Deep Enclosure

APC NetShelter SX 48U 750mm Wide x 1070mm Deep Enclosure

NetShelter SX 48U 750mm Wide x 1200mm Deep Enclosure

APC NetShelter SX 48U 750mm Wide x 1200mm Deep Enclosure

Features & Benefits:

Compatibility
Integrated with APC InfraStruXure products APC cooling, power distribution, and cable management products work seamlessly with the enclosures to provide a complete IT infrastructure support system.
Guaranteed compatibility Vendor-neutral mounting for guaranteed compatibility with all EIA-310 compliant 19" equipment. The APC "Fits Like a Glove" money back guarantee provides peace of mind that all of your EIA-310-D compliant rack-mount equipment will physically fit in a NetShelter SX enclosure.
Convenience
Cable Access Vendor-neutral mounting for guaranteed compatibility with all EIA-310 compliant 19" equipment. The APC "Fits Like a Glove" money back guarantee provides peace of mind that all of your EIA-310-D compliant rack-mount equipment will physically fit in a NetShelter SX enclosure.
Simple Selection No need to spend hours choosing from and compiling dozens of part numbers to create a single enclosure. APC has made it easy by handling the details and providing complete enclosures with single part numbers.
Ventilated Perforated front and rear doors provide ample ventilation for servers and networking equipment.
Quick release doors Front door can be moved to the opposite side or interchanged with rear doors. Doors are easily removed with simple lift-off design.
Half-height side panels Half-height quick release side panels reduce size and weight for easy handling and access to equipment. Side panels are lockable utilizing a single key with the doors.
Agility
Rear Cable Management channels Integrated and adjustable rear channel provides zero U mounting locations for toolless accessories. Each channel has two mounting bays to support a combination of up to four accessories such as PDUs and vertical cable organizers.
Adjustable mounting rails The vertical mounting rails can be adjusted in 1/4 in (6.4 mm) increments covering virtually any mounting requirement for IT equipment. U positions are numbered front and back for rapid installation of equipment.
Split rear doors Split rear doors improve access and serviceability to rear of rack mounted equipment. The split rear doors help to maximize floor space. Only 11 inches (279 mm) of clearance is required behind the enclosures to allow for door swing.
Adjustable leveling feet Leveling feet can be quickly adjusted through the use of a screwdriver or drill, eliminating the need to reach underneath with a wrench. Enclosures are shipped standard with both leveling feet and castors.
Overhead cable management Overhead cable troughs and partitions install toollessly on the roof of the enclosure eliminating the need for ceiling mounted or underfloor mounted cable trays. Cable troughs and partitions are designed to manage both power and data cables while maintaining separation.
Safety
Structural Stability A proven frame design, heavy-gauge mounting rails, and heavy-duty casters provide for 3000 lb (1364 kg) static and 2250 lb (1023 kg) dynamic load ratings.
Integrated electrical grounding The roof, side panels and front and rear doors are grounded to the frame of the enclosure. Eight additional electrical grounding inserts are located on the frame for external grounding.

Pricing Notes:

APC Products
APC NetShelter SX 24U 600mm Wide x 1070mm Deep Enclosure
APC NetShelter SX 24U 600mm Wide x 1070mm Deep Enclosure
#AR3104
Our Price: $1,149.95
APC NetShelter SX 24U 600mm Wide x 1070mm Deep Enclosure - 1250 lbs. Shock Packaging
#AR3104SP1
Our Price: $1,350.00
APC NetShelter SX 42U 600mm Wide x 1070mm Deep Enclosure
APC NetShelter SX 42U 600mm Wide x 1070mm Deep Enclosure
#AR3100
Our Price: $1,324.95
APC NetShelter SX 48U 600mm Wide x 1070mm Deep Enclosure
APC NetShelter SX 48U 600mm Wide x 1070mm Deep Enclosure
#AR3107
Our Price: $1,599.95
APC NetShelter SX 42U 750mm Wide x 1070mm Deep Enclosure
APC NetShelter SX 42U 750mm Wide x 1070mm Deep Enclosure
#AR3150
Our Price: $1,649.95
APC NetShelter SX 48U 750mm Wide x 1070mm Deep Enclosure
APC NetShelter SX 48U 750mm Wide x 1070mm Deep Enclosure
#AR3157
Our Price: $1,949.95
APC NetShelter SX 42U 600mm Wide x 1200mm Deep Enclosure
APC NetShelter SX 42U 600mm Wide x 1200mm Deep Enclosure
#AR3300
Our Price: $1,749.95
APC NetShelter SX 48U 600mm Wide x 1200mm Deep Enclosure
APC NetShelter SX 48U 600mm Wide x 1200mm Deep Enclosure
#AR3307
Our Price: $2,074.95
APC NetShelter SX 42U 750mm Wide x 1200mm Deep Enclosure
APC NetShelter SX 42U 750mm Wide x 1200mm Deep Enclosure
#AR3350
Our Price: $2,199.95
APC NetShelter SX 48U 750mm Wide x 1200mm Deep Enclosure
APC NetShelter SX 48U 750mm Wide x 1200mm Deep Enclosure
#AR3357
Our Price: $2,524.95
