APC Back-UPS ES 8 Outlet 650VA 120V

BE350R Features:

• Battery failure notification
• Battery replacement without tools
• Disconnected battery notification
• Intelligent battery management
• LED status indicators
• Replace Battery LED
• USB connectivity
• User-replaceable batteries

The most popular desktop UPS in the world!

APC's Back-UPS® ES series is now "greener" than ever. The ES 650 utilizes an ultra-efficient design that consumes less power during normal operation than any other battery backup in its class, saving you money on your electricity bill. It's also RoHS compliant, which means its manufacture and ultimate disposal is easier on the environment. Even the packaging has been carefully selected to minimize energy use in it's creation, and to maximize the use of recycled materials. Coupled with all the standard features of the Back-UPS ES series, the ES 650 is the best value for home and home office computers.

Features and Benefits:

Runtime Chart:

Technical Specifications:

Output

Output Power Capacity

390 Watts / 650 VA

Max Configurable Power

390 Watts / 650 VA

Nominal Output Voltage

120V

Output Frequency (sync to mains)

60 Hz

Waveform Type

Stepped approximation to a sinewave

Output Connections

(4) NEMA 5-15R (Battery Backup)
(4) NEMA 5-15R (Surge Protection)

Required Output Current Protection

15A

Input

Nominal Input Voltage

120V

Input Frequency

50/60 Hz

Input Connections

NEMA 5-15P

Cord Length

6 feet (1.83 meters)

Input voltage range for main operations

88 - 139V

Maximum Input Current

12A

Input Breaker Capacity

15A

Batteries & Runtime

Battery Type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time

16 hour(s)

Replacement battery cartridge

RBC17

RBC™ Quantity

1

Typical Backup Time
at Half Load

15.4 minutes (195 Watts)

Typical Backup Time
at Full Load

4.2 minutes (390 Watts)

Runtime Chart

Back-UPS ES

Communications & Management

Control panel

LED status display with On Line : On Battery : Replace Battery and Building Wiring Fault

Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge energy rating

365 Joules

Filtering

Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449

Dataline protection

RJ-45 Modem/Fax/DSL/10-100 Base-T protection,Co-axial Video / Cable protection

Physicall

Maximum Height

3.54 inches (90 mm)

Maximum Width

12.60 inches (320 mm)

Maximum depth

6.97 inches (177 mm)

Net Weight

14.30 lbs. (6.50 kg)

Shipping Weight

16.50 lbs. (7.50 kg)

Shipping Height

5.83 inches (148 mm)

Shipping Width

17.50 inches (445 mm)

Shipping Depth

10.20 inches (259 mm)

Master Carton Units

2.00

Master Carton Dimensions (Length x Width x Height)

18 x 12 x 11 inches (465 x 312 x 278 mm)

Master Carton Weight

35.20 lbs. (16.00 kg)

Color

Charcoal

SCC Codes

1073130425652 3

Units per Pallet

72.00

Environmental

Operating Environment

32 - 104°F (0 - 40°C)

Operating Relative Humidity

5 - 95%

Operating Elevation

0-10000 feet (0-3000 meters)

Storage Temperature

5 - 113°F (-15 - 45°C)

Storage Relative Humidity

5 - 95%

Storage Elevation

0-50000 feet (0-15000 meters)

Audible noise at 1 meter from surface of unit

45.00 dBA

Online Thermal Dissipation

15.00 BTU/hr

Conformance

Regulatory Approvals

FCC Part 15 Class B,FCC Part 68,TUV,UL 1778

Standard Warranty

3 years repair or replace

Equipment protection policy

Lifetime : $75000

*Except where noted, all prices are Estimated Resale Price (ERP) - Without Tax/VAT. Pricing in other locations and sites may vary.

Documentation:

Download the APC BE650G Data Sheet (PDF).
