APC Back-UPS ES 8 Outlet 550VA 120V

BE550G Features:

• Battery failure notification
• Battery replacement without tools
• Disconnected battery notification
• Intelligent battery management
• LED status indicators
• Replace Battery LED
• USB connectivity
• User-replaceable batteries

The most popular desktop UPS in the world!

APC's Back-UPS® ES series is now "greener" than ever. The ES 550 utilizes an ultra-efficient design that consumes less power during normal operation than any other battery backup in its class, saving you money on your electricity bill. It's also RoHS compliant, which means its manufacture and ultimate disposal is easier on the environment. Even the packaging has been carefully selected to minimize energy use in it's creation, and to maximize the use of recycled materials. Coupled with all the standard features of the Back-UPS ES series, the ES 550 is the best value for home and home office computers.

Features and Benefits:

Runtime Chart:

Technical Specifications:

Output

Output Power Capacity

330 Watts / 550 VA

Max Configurable Power

330 Watts / 550 VA

Nominal Output Voltage

120V

Output Frequency (sync to mains)

660 Hz

Waveform Type

Stepped approximation to a sinewave

Output Connections

(4) NEMA 5-15R (Battery Backup)
(4) NEMA 5-15R (Surge Protection)

Input

Nominal Input Voltage

120V

Input Frequency

60 Hz +/- 1 Hz

Input Connections

NEMA 5-15P

Cord Length

6 feet (1.83 meters)

Input voltage range for main operations

88 - 139V

Batteries & Runtime

Battery Type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time

24 hour(s)

RBC™ Quantity

1

Typical Backup Time
at Half Load

13.5 minutes (165 Watts)

Typical Backup Time
at Full Load

3.3 minutes (330 Watts)

Runtime Chart

Back-UPS ES

Communications & Management

Control panel

LED status display with On Line : On Battery : Replace Battery and Building Wiring Fault

Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge energy rating

365 Joules

Filtering

Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449

Dataline protection

RJ-11 Modem/Fax/DSL protection (two wire single line)

Physicall

Maximum Height

3.30 inches (84 mm)

Maximum Width

12.00 inches (305 mm)

Maximum depth

7.00 inches (178 mm)

Net Weight

13.00 lbs. (5.91 kg)

Shipping Weight

14.30 lbs. (6.50 kg)

Shipping Height

9.50 inches (241 mm)

Shipping Width

17.25 inches (438 mm)

Shipping Depth

5.50 inches (140 mm)

Master Carton Units

2.00

Master Carton Dimensions (Length x Width x Height)

18 x 11.5 x 10 inches (457 x 292 x 254 mm)

Color

Black

SCC Codes

1073130425894 7

Environmental

Operating Environment

32 - 104 °F (0 - 40 °C)

Operating Relative Humidity

5 - 95%

Operating Elevation

0-10000 feet (0-3000 meters)

Storage Temperature

5 - 113 °F (-15 - 45 °C)

Storage Relative Humidity

5 - 95%

Storage Elevation

0-50000 feet (0-15000 meters)

Audible noise at 1 meter from surface of unit

45.00 dBA

Online Thermal Dissipation

16.00 BTU/hr

Conformance

Regulatory Approvals

cUL Listed,FCC Part 15 Class B,FCC Part 68,NOM,UL 1778,UL 497A,UL 497B

Standard Warranty

3 years repair or replace

Equipment protection policy

Lifetime : $75000

*Except where noted, all prices are Estimated Resale Price (ERP) - Without Tax/VAT. Pricing in other locations and sites may vary.

Documentation:

Download the APC BE650G Data Sheet (PDF).
